YOV5050DP

* Ultra-High Stability
* Temperature Stability ≤ ±1E-11 (-40℃~70℃)
* Short-Term stability ≤ 8E-12 @ 1s
*  Aging≤  ± 5E-11/day

Datasheet Contact Us
Parameter Table
Sample
Specifications :
Specification Value
Frequency Range 5~120 MHz
Supply Voltage 5 V / 12 V
Temperature Stability ≤ ±0.01 ppb (best achievable, +40°C to +70°C)
Operating Temperature −40°C ~ +70°C
Output Type Sine Wave / HCMOS
Short-Term Stability < 8 × 10⁻¹² @ 1 s
Phase Noise @ 1 kHz −158 dBc/Hz (10 MHz)
Package Size 50.8 × 50.8 × 15.0 mm


Features:

♦  Ultra-high temperature stability as tight as ±0.01 ppb over +40°C to +70°C.

♦  Wide frequency range from 5 MHz to 120 MHz.

♦  Low phase noise of −158 dBc/Hz at 1 kHz offset (10 MHz).

♦  Short-term stability of < 8 × 10⁻¹² at 1 second.

♦  Low aging rate of ≤ 0.1 ppb/day.

♦  Sine wave and HCMOS output options.

♦  Supply voltage options of 5 V and 12 V.

♦  Warm-up time of less than 15 minutes.

♦  50.8 × 50.8 × 15.0 mm package.




Applications:

♦  Routers

♦  Switching Equipment

Submit

Voltage : 5V, 12V

Frequency : 5~120MHz

Dimension : 50.8x50.8x15.0

Operating Temp : -40~+70℃

Frequency Tolerance : ≤±0.01ppb@-40~+70℃

Output : Sine Wave / HCMOS
