YOV3627DP

*  Small Size, High Stability
*
High Short-Term Stability≤1.5E-13@1s

* Temperature  Stability≤±1E-10(-40℃ to 70℃)
* Aging ≤±1E-10/day

Datasheet Contact Us
Parameter Table
Sample
Specifications :
Specification Value
Frequency Range 5~20 MHz
Frequency Tolerance ≤ ±0.1 ppb (best achievable) @-40~+70℃
Operating Temperature −40°C ~ +70°C
Output Type Sine Wave / HCMOS
Short-Term Stability < 1.5 × 10⁻¹³ @ 1 s
Phase Noise @ 1 kHz −165 dBc/Hz min. (10 MHz)
Package 36 × 27 × 12.7 mm

Features:

♦  High temperature stability as tight as ±0.1 ppb over +40°C to +70°C.

♦  Ultra-low phase noise of −165 dBc/Hz at 1 kHz offset (10 MHz).

♦  Excellent short-term stability of less than 1.5 × 10⁻¹³ at 1 second.

♦  Frequency range from 5 MHz to 20 MHz.

♦  Sine wave and HCMOS output options.

♦  Supply voltage options of 3.3 V, 5 V, and 12 V.

♦  Low aging rate of ≤ ±0.1 ppb/day.

♦  Warm-up time of less than 5 minutes.

♦  Compact 36 × 27 × 12.7 mm package.



Applications:

♦  Routers

♦  Switching Equipment

Submit

Voltage : 3.3V, 5V, 12V

Frequency : 5~20MHz

Dimension : 36x27x12.7

Operating Temp : -40~+70℃

Frequency Tolerance : ≤±0.1ppb@-40~+70℃

Output : Sine Wave / HCMOS

Series : Ultra-Low Noise, High Short-Term Stability OCXO
