YOV2525DP

* Small Size, High Cost-Performance
* Temperature Stability≤0.2ppb(-40~+85℃)
* Aging≤ 0.2ppb/day

Datasheet Contact Us
Parameter Table
Sample

Specifications :
Specification Value
Frequency Range 80~100 MHz
Supply Voltage 3.3 V / 5 V / 12 V
Temperature Stability ≤ ±0.2 ppb (best achievable, +40°C to +85°C)
Operating Temperature −40°C ~ +85°C
Output Type Sine Wave / HCMOS
Short-Term Stability ≤ 8 × 10⁻¹² @ 1 s
Phase Noise @ 1 kHz −165 dBc/Hz min. (80 MHz)
Package Size 25.4 × 25.4 × 12.7 mm


Features:

♦  High-frequency output range from 80 MHz to 100 MHz.

♦  Ultra-low phase noise of −165 dBc/Hz at 1 kHz offset (80 MHz).

♦  High temperature stability as tight as ±0.2 ppb over +40°C to +85°C.

♦  Short-term stability of < 8 × 10⁻¹² at 1 second.

♦  Low aging rate of ≤ 0.2 ppb/day.

♦  Sine wave and HCMOS output options.

♦  Supply voltage options of 3.3 V, 5 V, and 12 V.

♦  Warm-up time of less than 5 minutes.

♦  Compact 25.4 × 25.4 × 12.7 mm package.


Applications:

♦  Base Stations

♦  Medical Equipment

Submit

Voltage : 3.3, 5V, 12V

Frequency : 80~120MHz

Dimension : 25.4x25.4x12.7

Operating Temp : -40~+85℃

Frequency Tolerance : ≤±0.2ppb@-40~+85℃

Output : Sine Wave / HCMOS

Series : Ultra-Low Phase Noise, High-Frequency OCXO
