YOV2525DP

* Ultra-High Frequency Stability

* Ultra Wide Frequency Range

* Ultra Low Phase Noise

* Ultra Compact OCXO Package

Datasheet Contact Us
Parameter Table
Sample
Specifications :

Specification Value
Frequency Range 5~120 MHz
Supply Voltage 3.3 V / 5 V / 12 V
Temperature Stability ≤ ±0.2 ppb (best achievable, +40°C to +85°C)
Operating Temperature −40°C ~ +85°C
Output Type Sine Wave / HCMOS
Short-Term Stability < 8 × 10⁻¹² @ 1 s
Phase Noise @ 1 kHz −155 dBc/Hz min. (80 MHz)
Package Size 25.4 × 25.4 × 12.7 mm


Features:

♦  Ultra-high temperature stability as tight as ±0.2 ppb over +40°C to +85°C.

♦   Wide frequency range from 5 MHz to 120 MHz.

♦   Low phase noise of −155 dBc/Hz at 1 kHz offset (80 MHz).

♦   Short-term stability of < 8 × 10⁻¹² at 1 second.

♦   Low aging rate of ≤ 0.2 ppb/day.

♦   Sine wave and HCMOS output options.

♦   Supply voltage options of 3.3 V, 5 V, and 12 V.

♦   Warm-up time of less than 5 minutes.

♦   Compact 25.4 × 25.4 × 12.7 mm package.


Applications:

♦   Base Stations

♦   Medical Equipment

Submit

Voltage : 3.3V, 5V, 12V

Frequency : 5~120MHz

Dimension : 25.4x25.4x12.7

Operating Temp : -40~+85℃

Frequency Tolerance : ≤±0.2ppb@-40~+85℃

Output : Sine Wave / HCMOS
